Pregy CDO 67/S4927 - 1 PH BA13

Double frame ceiling with 1 x 12,5 mm Pregydro H2 BA13, fixed to galvanized steel frame made of 28-28-28 mm U tracks and 27-49-27 mm S4927 channel at 100 cm spacing and at 50 cm respectively the primary and the secondary, with hangers at 120 cm. Mineral wool (Optional) in the cavity

Pregy CDO 67/S4927 - 1 PH BA13

Further Information

Nominal thickness: 67 mm
Framing centres: 1000 mm
Framing centres(2): 500 mm
Insulation type: Mineral wool
Maximum hanger span: 1200 mm
Secondary channel interval: 500 mm
Fire reaction: A2-s1,d0
Performance: Moisture
Support: Any kind

Applications:

  • Used to enhance thermal and acoustic performances of the soffit
  • Used where services are required below the soffit
  • New buildings and renovations
